KCHR-8I/BP Side Wind All In One Heat Pump Water Heater 3.88 COP

Ask Lasest Price
Brand Name :	LN
Model Number :	KCHR-8I/BP Side wind
Certification :	CB, CE, EMC, RoHS
Price :	NegotiableDomestic Air Source Heat Pump All In One Heat Cooling And Hot Water9DHW) With Enamel Water Tank
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	50,000pcs/year
Delivery Time :	1-30 days

Add to Cart

Product Details
Company Profile

KCHR-8I/BP Side Wind All In One Heat Pump Water Heater 3.88 COP

Product Introduction of High Efficiency Air Source Heat Pump Water Heater
A heating device that absorbs the heat energy of the air in the environment to heat water, because the power consumption is only 1/4 to 1/3 of the direct electric heating method, and it is less affected by the regional environment, and it can operate stably throughout the year Therefore, the air-energy hot water machine has become a new energy-saving hot water heating device. According to whether the compressor is equipped with a jet enthalpy increase device, the air-energy cold and hot water machines are divided into two categories: conventional type and ultra-low temperature type. Among them, the conventional air-energy hot water machine can operate stably for a long time in the environment of -7℃~43℃ , The ultra-low temperature air-energy water heater runs stably for a long time in the environment of -26℃~43℃.

Product Usage of High Efficiency Air Source Heat Pump Water Heater
It is suitable for hot water supply in homes, schools, hospitals, hotels, SPA clubs and other occasions.

Performance characteristics
1. Adopt special compressor for heat pump, with high thermal efficiency and long life. The ultra-low temperature model is equipped with the quasi-two Yasuo jet enthalpy system to realize stable operation at -26℃.
2. The unique enhanced evaporator structure and high-efficiency piping system can effectively improve the winter energy efficiency ratio and reduce the frosting rate. With the intelligent heat pump defrosting system, it can ensure the energy efficiency of the heat pump in humid and low temperature.
3. Modular design, which can realize the joint control and remote monitoring of 16 units. Each unit has an independent frame structure, heating system, power distribution system, control system and protection function. When one of the units fails, it will not affect The normal operation of other units.
4. The advanced intelligent control system has comprehensive protection functions such as high pressure protection, low pressure protection, water shortage protection, leakage protection, phase loss protection, overload protection, antifreeze protection, and exhaust temperature overheat protection. It is convenient and simple to manage.

Specification of High Efficiency Air Source Heat Pump Water Heater

Triple supply parameters Cooling, heating and hot water functions
Item		KCHR-8I/BP Side wind	KCHR-13I/BP Side wind)	KCHR-15I/BP Side wind	KCHR-15II/BP (Out of the wind)
Rated voltage		220V~50Hz	220V~50Hz	220V~50Hz	380V 3N~50Hz
Cooling and heating	Nominal cooling capacity	7.8kW(2kW-9kW)	13kW(3kW-15kW)	14.5kW(4kW-16.5kW)	14.5kW(4kW-16.5kW)
	Nominal cooling power consumption	2.77KW	4.6KW	5.27KW	5.27KW
	Nominal cooling(COP)	2.81	2.82	2.75	2.75
	IPLV	4.11	4.13	4.02	4.02
	Nominal heating capacity	8.4kW(2.5kW-9.6kW)	14kW(3.5kW-16kW)	17kW(4.3kW-18.5kW)	17kW(2.5kW-18.5kW)
	Nominal heating power consumption	2.78KW	4.5KW	5.6KW	5.6KW
Heating	Nominal heating capacity	6.8KW	10.5KW	13KW	13KW
	Nominal heating power consumption	1.75KW	2.65KW	3.3KW	3.3KW
	Nominal heating(COP)	3.88	3.96	3.93	3.93
Maximum operating current		20A	33A	41A	21A
Maximum power consumption		4KW	6.6KW	7.9KW	7.9KW
Rated water flow		1.34m²/h	2.24m²/h	2.5m²/h	2.5m²/h
Refrigerant/charge volume		R410A/1750g	R410A/4000g	R410A/4000g	R410A/4800g
noise		≤54dB(A)	≤56dB(A)	≤57dB(A)	≤58dB(A)
Water resistance		≤14kPa	≤15kPa	≤21kPa	≤21kPa
Maximum working pressure on low pressure/high pressure side		4.5Mpa/0.15Mpa	4.5Mpa/0.15Mpa	4.5Mpa/0.15Mpa	4.5Mpa/0.15Mpa
Allowable working pressure on suction/exhaust side		4.5Mpa/0.15Mpa	4.5Mpa/0.15Mpa	4.5Mpa/0.15Mpa	4.5Mpa/0.15Mpa
Anti-shock level		I	I	I	I
waterproof level		IPX4	IPX4	IPX4	IPX4
Unit size (l× w × h)		1030×410×865(mm)	1030×410×1390(mm)	1030×410×1390(mm)	820×780×1700(mm)
(Cold and warm) Caliber of inlet and outlet		DN25	DN32	DN32	DN32
(Hot water) Caliber		DN20	DN25	DN25	DN25
