Features of Heating And Cooling With Domestic Hot Water For House Bathroom
Usage
This is a built-in water tank air energy heat pump heating and
heating system, including a unit part, a heating part, a heating
part and an intelligent control part. The unit part includes an air
heat pump heating part, an electric heating part, a water pipeline
part and a control circuit Part; The control circuit part is used
to start the compressor for heating according to the temperature of
the small-capacity water tank is lower than the compressor start
temperature difference. When the temperature is detected to reach
the set temperature, the electric heating part is controlled to not
output; when it is detected that the set temperature cannot be
reached According to the detected temperature difference between
the inlet and outlet water and the detected flow rate of the water
pipeline parts, the electric heating power required for the output
of the electric heating part is controlled; when the heating part
of the air energy heat pump and the electric heating part are both
full power output, the temperature of the small-capacity water tank
is still When the set temperature has not been reached, the water
pipe parts are controlled according to the detected temperature to
adjust the water flow through the water flow adjustment valve to
keep the water temperature constant.
Company introduction:
Leomon technology rnjoy rich experience in supplying air source
heat pumps, supply its own brand and OEM for customers worldwide.
Products series: air source heat pumps for household, water heater,
swimming pool heat pumps, heating system
Keep working at technical and commercial ability, company is
athorized over 300 patents, norminated factory for supplying heat
pumps.
Quality Control:
100% products inspection before delivery, 3 phrases test to
guarantee right quality and quantity before delivery
Whole lifespan after sale service
| Low temperature hot water unit parameters |
| Spec. | DKFXRS-11I/R |
| Nominal heating capacity at room temperature(kW) | 113 |
| Nominal heating at room temperature(kW) | 2.56 |
Low-temperature
nominal heating
capacity(kW) | 4.8 |
| Low temperature nominal heating(kW) | 2.1 |
| Maximum input power(kW) | 4.2 |
| Maximum current(A) | 23 |
| Power Specifications(Hz) | 220V ~ 50 |
| Refrigerant/charge amount | R22/5600g |
| noisedb(A) | <62 |
| Water resistancekPa | <55 |
| Anti-shock level | I |
| waterproof level | IPX4 |
Caliber of inlet
and outlet | DN32 |
| Unit size (mm) | 1030x410x1390 |
| Unit Weight(kg) | 142 |
