Features of Air Source Heat Pump for Cooling and Heating House Suppliers
An ultra-low temperature air energy heat pump unit provides an
ultra-low temperature air energy heat pump unit with simple
structure, automatic defrosting of the condenser, good defrosting
effect, and energy saving, which solves the existing air energy
heat pump unit in the prior art In the case of ultra-low
temperature, the condenser cannot be defrosted normally, and the
defrosting effect is poor. In severe cases, the air energy heat
pump water heater or heating air conditioner cannot work normally
and other technical problems. It includes the water tank and the
outdoor unit. A heat exchanger is installed in the water tank. The
outdoor unit is equipped with a compressor and a condenser
connected to the compressor through a pipeline. The output and
input ends of the heat exchanger are respectively connected to the
condenser through upper and lower connecting pipes. The condenser
is equipped with a condenser sensor and Several sets of heating
fins, the heating fins are parallel to the condenser fins and fixed
on the copper tube of the condenser. A water temperature sensor is
installed in the water tank. The compressor, heating fins,
condenser sensor and water temperature sensor pass the controller
Next Generation R32 EcoCore Technology
R32 is a refrigerant with just one-third the global warming
potential of R410A and has zero ozone depletion potential. R32
offers increased energy efficiency, and is said to be the next
generation of refrigerants
Washable Air Purifying Filter
This is equipped with an Air Purifying Filter. This washable filter
traps particles such as dust, pollen and other airborne
contaminants, generating stable antibacterial and deodorising
effects. The size of the three-dimensional surface has been
increased from previous models, enlarging the filter capture area.
These features give the Air Purifying Filter better dust collection
performance than conventional filters.
Some specifications of Air Source Heat Pump for Cooling and Heating House Suppliers
| Spec. | DKFXRS-11I/R | DKFXRS-11II/R | DKFXRS-16I/R | DKFXRS-16II/R |
| Nominal heating capacity at room temperature(kW) | 113 | 10.9 | 16 | 16.8 |
| Nominal heating at room temperature(kW) | 2.56 | 2.65 | 3.9 | 4.1 |
Low-temperature
nominal heating
capacity(kW) | 4.8 | 4.75 | 7.9 | 8.1 |
| Low temperature nominal heating(kW) | 2.1 | 2.15 | 3.38 | 3.5 |
| Maximum input power(kW) | 4.2 | 4.2 | 6.6 | 6.8 |
| Maximum current(A) | 23 | 8 | 32 | 12 |
| Power Specifications(Hz) | 220V ~ 50 | 380V 3N ~ 50 | 220V ~ 50 | 380V 3N ~ 50 |
| Refrigerant/charge amount | R22/5600g | R22/5600g | R22/6000g | R22/6000g |
| noisedb(A) | <62 | <62 | <65 | <65 |
| Water resistancekPa | <55 | <55 | <100 | <100 |
| Anti-shock level | I |
| waterproof level | IPX4 | IPX4 | IPX4 | IPX4 |
Caliber of inlet
and outlet | DN32 | DN32 | DN32 | DN32 |
| Unit size (mm) | 1030x410x1390 | 1030x410x1390 | 1030x410x1390 | 1030x410x1390 |
| Unit Weight(kg) | 142 | 142 | 148 | 149 |
Some projects of Air Source Heat Pump for Cooling and Heating House
Suppliers
About the detailed information of service, you can contact with our
sales personnel!
