CE Low Temperature EVI Air Source Heat Pump 60HZ EVI For Office Buildings

Brand Name :

Model Number :

KCHR-8I/BP Side wind

Certification :

CB, CE, EMC, RoHS

Price :

Negotiable

Payment Terms :

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability :

50,000pcs/year

Delivery Time :

1-30 days

CE Low Temperature EVI Air Source Heat Pump 60HZ EVI For Office Buildings

We are proud to announce the launch of our new Inverter+ commercial range of inverter driven heat pumps

The largest capacity Inverter pool heat pump on the market

The leader for EVI air to water heatpumps factory

Over 300 patents, decades experience, patents parts intergration, flexible installtion, high COP, high effective

Heat pumps working very well till -30℃

Leomon heat pump allows to reduce up to 80% of the energy consumption of a house, using a renewable source of energy that minimizes the CO2 emissions to the environment.

Years of reserch and studying, Our R&D department was able to produce a very compact and easy to install heat pump keeping on it all the controls necessary to regulate your house temperature. our heat pumps is able to work in very extreme weather conditions(-30℃) keeping it's high performance.

An icing and antifreezing device for a casing heat exchanger and a manufacturing method thereof are adopted, and belong to the field of heat pumps. This
A tube-in-tube heat exchanger icing and anti-freezing device includes a tube-in-tube heat exchanger composed of a concentric inner tube and an outer tube, and a plurality of inflatable elastic balls are arranged at equal intervals in the inner tube. The inflatable elastic ball is a butyl rubber ball. The gas inflated inside the inflatable elastic ball is nitrogen. Furthermore, the inflatable elastic ball is adhered and fixed to the inner tube. The diameter of the inflatable elastic ball is half of the diameter of the inner tube. Furthermore, the total volume of the inflatable elastic ball is 0.4 times the internal volume of the inner tube. It can achieve the effects of not being easy to freeze and anti-freezing, and has a simple structure and low cost.

About the problems in the prior art that the hot water supply pressure of the existing large-capacity water system cannot be balanced, the water at the end is hot and cold, and the capacity tonnage is large, the utility model provides a modular pressure-bearing heat pump system, including a host , It also includes a heating water tank and several hot water storage tanks connected in series through the circulation pipeline. The water supply pipe connected to the municipal pipe network of the tap water is respectively connected to the heating water tank and the first-level hot water storage tank. Several levels of hot water storage tanks pass The circulation pipeline is finally connected with the heating water tank, the heating water tank is connected with the cold water pipeline and the hot water pipeline of the host; the heating water tank and the last-stage hot water storage tank are connected with the hot water supply pipe. Through the effective setting and control of the controller, it can realize the equilibrium of the terminal water pressure, the temperature is appropriate, the energy consumption is low, and a large amount of power equipment is not required

Spec.	DKFXRS-11I/R	DKFXRS-11II/R	DKFXRS-16I/R	DKFXRS-16II/R
Nominal heating capacity at room temperature(kW)	11.3	10.9	16	16.8
Nominal heating at room temperature(kW)	2.56	2.65	3.9	4.1
Low-temperature nominal heating capacity(kW)	4.8	4.75	7.9	8.1
Low temperature nominal heating(kW)	2.1	2.15	3.38	3.5
Maximum input power(kW)	4.2	4.2	6.6	6.8
Maximum current(A)	23	8	32	12
Power Specifications(Hz)	220V ~ 50	380V 3N ~ 50	220V ~ 50	380V 3N ~ 50
Refrigerant/charge amount	R22/5600g	R22/5600g	R22/6000g	R22/6000g
noisedb(A)	<62	<62	<65	<65
Water resistancekPa	<55	<55	<100	<100
Anti-shock level	I
waterproof level	IPX4	IPX4	IPX4	IPX4
Caliber of inlet and outlet	DN32	DN32	DN32	DN32
Unit size (mm)	1030x410x1390	1030x410x1390	1030x410x1390	1030x410x1390
Unit Weight(kg)	142	142	148	149

Spec.	DKFXRS-19II/R	DKFXRS-38II/R	DKFXRS-95II/R	DKFXRS-190II/R
Nominal heating capacity at room temperature(kW)	18.6	38.8	90	190
Nominal heating at room temperature(kW)	4.5	8.8	19.5	43
Low-temperature nominal heating capacity(kW)	8.6	17.7	42	84
Low temperature nominal heating(kW)	3.7	7.35	16.3	32.6
Maximum input power(kW)	8.3	17	40	80
Maximum current(A)	15	30	88	176
Power Specifications(Hz)	380V3N ~ 50	380V3N ~ 50	380V 3N ~ 50	380V 3N ~ 50
Refrigerant/charge amount	R22/6500g	R22/6700gx2	R410A/8500gX2	R410A/8500gX4
noisedb(A)	<66	<68	<78	<81
Water resistancekPa	<100	<100	<100	<123
Anti-shock level	I
waterproof level	IPX4	IPX4	IPX4	IPX4
Caliber of inlet and outlet	DN32	DN40	DN50	DN75
Unit size (mm)	780x820x1700	1550x780x1700	2206x1030x2170	2206x2020x2170
Unit Weight(kg)	263	431	750	1200

FAQ:

Q1.What does Leomon Technology do and strength?
A:Leomon Technology is a professional manufacturer enjoy over 20 years experience in refrigeration and heating industry. We are leader member and as mainly manager for edditing several air source heat pumps standard. Over 300 patents, our heat pumps are widely used for villas, buildings, commercial buildings, etc

Q2. What is your product series and application?

A: We make full range heat pump products involving air to water heat pump, water to water heat pump ,heat pump drier , industrial water cooled chiller ,swimming pool heat pump and some other relative products . Used for swimming pool, spa, buildings, household, cold places, for heating, cooling, hot water(DHW)

Q3. I am not professional, how do i choose?
A: We have professional technical team, we can offer you plan, just need to tell your application.

Q4. How about the delivery time?
A: If stock, can delivery same day

Q5. What is the MOQ ?
A: You can order even 1 pc, no MOQ request

Q6. OEM order is ok ?
A: Yes. OEM brand is accepted. Please provide your logo and brand authorization to us before production .

Q7: What's the warranty time?
A: 24 month.

Q8. What about quality control?

A: 3C certification, 100% products inspection, free spares supply, free technical support for customers!
