This heat pumps apply an energy storage interconnected heat pump
defrosting device with slow frost formation is adopted, including
an energy storage interconnected heat pump body, the energy storage
interconnected heat pump body is provided with a heat pump chamber
inside, and the left side of the energy storage interconnected heat
pump body is fixedly connected There is an intake pipe, the right
side of the energy storage interconnected heat pump body is fixedly
connected with a water outlet, the right side of the energy storage
interconnected heat pump body is fixedly connected with a water
inlet, and a water storage tank is fixedly installed inside the
heat pump chamber. The invention effectively removes the frost
layer inside the energy storage interconnected heat pump body, so
that the hot air inside the energy storage interconnected heat pump
body enters the defrosting pipe from the air inlet, and leaves the
defrosting pipe through the air outlet, so that the hot air faces
the outside of the evaporator The frost layer is removed to achieve
the defrosting effect, thereby reducing the forming efficiency of
the frost layer, and achieving the advantages of slow frost
formation, which effectively solves the problem that the existing
energy storage interconnected heat pump cannot effectively remove
the frost layer and affect the storage The problem of
interconnecting the use of heat pumps
| Constant temperature swimming pool heat pump |
| Spec. | KRY-8II | KRY-12II | KRY-24II | KRY-48II |
| Rated heating capacity(A24/26oC) | 8kw | 12kw | 24kw | 48kw |
| Rated power(kW) | 1.56 | 2.35 | 4.7 | 9.3 |
| COP | 5.1 | 5.1 | 5.1 | 5.16 |
| Rated heating capacityA20/26oC | 7.5kw | 11kw | 21kw | 44 kw |
| Rated power(kW) | 1..5 | 2.3 | 4.5 | 8.6 |
| COP | 5 | 4.78 | 4.66 | 5.11 |
| Cooling Capacity(kW) | 3.8 | 5.7 | 11.3 | 23.7 |
| Consumed Power(kW) | 1.67 | 2.5 | 4.9 | 9.1 |
| EER | 2.3 | 2.3 | 2.3 | 2.6 |
| Rated voltage(Hz) | 220V 50HZ | 220V 50HZ | 380V 3N-50HZ | 380V 3N-50HZ |
| Maximum input power(kW) | 2 | 3 | 6 | 12 |
| Maximum current(A) | 8 | 12 | 24 | 42 |
| Water flownWh | 2.3 | 3.5 | 7 | 13 |
| noise dB(A) | <50 | <50 | <65 | <68 |
| Anti-shock level | I | I | I | I |
| waterproof level | IPV4 | IPV4 | IPV4 | IPV4 |
| Unit size (mm) | 910x350x835 | 1030x410x865 | 780x820x1700 | 1550x780x1700 |
| Unit Weight(kg) | 65 | 95 | 260 | 380 |
| Constant temperature swimming pool heat pump |
| Spec. | KRY-96II | KRY-145II | KRY-220II |
| Rated heating capacity(A24/26oC) | 96kw | 145kw | 220kw |
| Rated power(kW) | 18.5 | 23.6 | 42.5 |
| COP | 5.41 | 6.14 | 5.17 |
| Rated heating capacityA20/26oC | 90kw | 138kw | 208kw |
| Rated power(kW) | 17.5 | 24.1 | 41.5 |
| COP | 5.14 | 5.73 | 5 |
| Cooling Capacity(kW) | 40 | 58.1 | 98 |
| Consumed Power(kW) | 18.2 | 24.2 | 39 |
| EER | 2.2 | 2.4 | 2.5 |
| Rated voltage(Hz) | 380V 3N-50HZ | 380V 3N-50HZ | 380V 3N-50HZ |
| Maximum input power(kW) | 24 | 36.5 | 61 |
| Maximum current(A) | 80 | 90 | 130 |
| Water flownWh | 32 | 41 | 62 |
| noise dB(A) | <69 | <71 | <73 |
| Anti-shock level | I | I | I |
| waterproof level | IPV4 | IPV4 | IPV4 |
| Unit size (mm) | 1550x1550x1700 | 2360x1550x1840 | 2206x2020x2170 |
| Unit Weight(kg) | 760 | 2100 | 4005 |
FAQ:
Q:Why choose air to source heat pump?
A:1.It can get 4-5 times more heat than the traditional water
heater. Therefore,the heating efficiency is higher.
2.Heating with air heat source is safer than electric heating.
3.Even when it is snowing in winter, you can enjoy the 24-hour hot
water service provided by the air energy water heater at any time.
4.The heat pump product has no fuel emissions,can be controled by
Wifi.
Q:What service do you offer?
A:.We offer OEM/ODM or our brand, strong technical team, decades
experience, leader member for editting the heat pumps standard
Q:What is needed to buy a heat pumps?
A:Please tell the application of heat pumps, sizes need to be
heated, then we will match accordingly
