CO2 R744 High Temperature Heat Pump Up To 90c Degree

Ask Lasest Price
Brand Name :	LN
Model Number :	SJKRS-I60II /C
Certification :	CE ISO CCC ROHS
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	80000pcs/year
Delivery Time :	1-30 working days

Add to Cart

Product Details
Company Profile

CO2 R744 High Temperature Heat Pump Up To 90c Degree

Performance of CO2 R744 High Temperature Heat Pump up to 90c Degree

CO₂ heat pumps use energy from the environment to generate heat. Non-flammable carbon dioxide is an exceptionally eco-friendly refrigerant, so CO₂ heat pumps can considerably reduce harmful emissions. CO₂ is also an excellent refrigerant because it is not flammable and there is an abundance of it on earth.

DC Inverter CO2 (R417 R744) Heat Pump High Cop Cooling & Heating Heat Pumps

How to heat, the smarter way

You can save more on your energy bills—and contribute to a cleaner, greener and more sustainable future—with Automatic Heating Global’s CO2 Heat Pumps.

Boasting an efficiency around four times that of conventional electric water heating technology, Revere™ CO2 Heat Pumps use minimal power and clever technology to heat your water to 90°C by extracting heat from the ambient air. Better yet, this process does not contribute to global warming, or run any of the risks associated with traditional combustion.

CO2 R744 High Temperature Heat Pump up to 90c Degree specifications

Unit type		SJKRS-28 II/C	SJKRS-36II/C	SJKRS-55 II/C	SJKRS-73 I/C	SJKRS-106 IC	SJKRS-I60II /C
Specifications		7.5HP	10HP	15HP	20HP	30HP	40HP
Power supply		Three-phase five-wire380V/50Hz
Heating mode		Direct heat/cycle type
Standard working condition	Heating capacity( kw )	27.5	36.7	55.1	72.8	10.6.5	155.1
	Input Power(kW)	6.1	8.2	13.7	16.1	23.6	34.5
	COP	4.5	4.5	4.5	4.5	4.5	4.5
	Hot Water flow(m³/h)	0.59	0.79	1.18	1.56	2.29	3.33
High temperature condition	Heating capacity kw )	23.9	28.5	51.5	59.5	89	13.1.5
	Input Power(kW)	7.5	8.9	16.1	18.6	27.8	41.1
	COP	3.2	3.2	3.2	3.2	3.2	3.2
	Hot Water flow(m³/h)	0.27	0.33	0.59	0.68	1.02	1.51
Low temperature condition	Heating capacity( kw )	17.3	21.4	34.8	41.5	62.2	94.5
	Input Power(kW)	6.2	7.6	12.4	14.8	22.2	33.8
	COP	2.8	2.8	2.8	2.8	2.8	2.8
	Hot Water flow(m³/h)	0.32	0.4	0.65	0.78	1.16	1.77
Component Information	Size of water pipe joint	DN20		DN25		DN32	DN40
	Water heat exchanger	Plate or sleeve heat exchanger
	Air Heat Exchanger	Aluminum Fin for copper tube
	compressor type	Semi-closed reciprocating
	Operation Panel	Color touch screen
Maximum outlet temperature(℃)		90℃
Refrigerants		R744 (CO2 )
Design pressure(MPa)		High side 15, low side 8
Dimensions (length, width and height mm)		1450x950x1450	1600x950x1500	1850x1150x1900	2050x1150x1950	2670x1410x2150	2290x2270x1980
Noise (dB)		56	59	62	67	70	70
Weight(kg)		550	660	780	860	1180	221360
SCOPE of use	Feed water temperature(℃)	5~ 40
	Feed water pressure	0.05~ 0.4
	Effluent temperature(℃)	55~ 90
	Maximum flow	1.2	1.5	2.4	3.2	4.9	6.5
	Ambient temperature(℃)	’-20~43
